Package Size 540.00cm * 130.00cm * 160.00cm Package Gross Weight 4000.000kg Main Technical Data Main Accessories Related
Basic Info.
Model NO. XHH-C160
Customized Customized
Condition New
Control Type Ipc Computer Controlling System
Automatic Grade Automatic
Hydraulic Motor Power 11kw
Voltage 380V/ 50Hz/ 3pH
Motor Power 15kw
Effective Width 160mm
Molde Change Auto Change
Material Strip Thickness 0.8-2mm
Material for Puncher SKD-11
Shaft Material SKD-11
Material for Cutter SKD-11
Control System Ipc Computer Controlling System
After-Sales Service Provided Engineers Available to Service Machinery Overseas
Transport Package Paking
Specification 5400*1300*1600mm
Trademark XHH
Origin Fujian, China(Mianland)
HS Code 84552290
Production Capacity 20stes/Month
Packaging & Delivery
Package Size 540.00cm * 130.00cm * 160.00cm Package Gross Weight 4000.000kg
Product Description

Main Technical Data

Main Servo Motor Power15KW
Hydraulic Motor11kw
Forming Steps12Steps
Forming Speed4-7tons/8hours
Effective Width160mm
Material Width255mm
Flange Height41mm
Material Thickness0.8-2.0mm
Tolerance for cutting and punching±1mm
Tolerance for forming±1mm
Control SystemIPC Computer Controlling System
Design SoftwareVertex Software
Material for All RollerSKD-11 steel with heat treatment, plate hard chrome on the surface of rollers
Material for ShaftSKD-11
Material for PuncherSKD-11
Material for CutterSKD-11

Main Accessories

1 Main Forming Machine
2 3 Tons Hydraulic Uncoiler
3 Servo Motor System
4 IPC Computer Controlling System (Lenovo Laptop)
5 Production Software (1set)
6 Design Software-Vertex,forever using license
7 Hydraulic Automatic Punching Device
(Web/Lip Notch,Swage,Service Hole,Chamfer,Dimple,Bolt Hole)
8 Hydraulic Post-cutting Device (Material:SKD-11)
9 Automatic Printing Device
10 Run Out Table (4m)
11 Operation Manual

Full-Automatic Prefabricated Building Lgs Steel Keel Framing Machine

Related Products
XHH C63-140
XHH-89-JC Model
XHH-89-5S Model
XHH-140 Model
XHH-310 Model

Full-Automatic Prefabricated Building Lgs Steel Keel Framing Machine

Full-Automatic Prefabricated Building Lgs Steel Keel Framing Machine

Q1.Are you a trading company or manufacture.1A: We are a factory.Q2. Do you provide samples ? Is it free or extra ?2A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.We could offer the sample for free charge3Q: Where is your factory located?3A: Our factory is located in Xiamen City, Fujian Province, China. You are warmly welcome to visit us !4Q: Can you make the machine according to my design or prototype?4A: Yes. We have an professional designer for working out the most suitable design and production plan for the machine that you are going to book with us5Q: How can I trust you that machines pasted testing running before shipping?5A: 1) We record the testing video for your reference. 2) You are welcome to visit us and test machine in our factory. 6Q: Do you provide installing and training overseas?6A: Overseas machine install and worker training services are optional.7Q: How is your after sales support?7A: We provide technical support on line as well as overseas services by skillful technicians.8Q: Guarantee period:8A: Within one year since the date of finishing commissioning.
